TSOP18..QJ3V

Vishay Telefunken

Photo Modules for PCM Remote Control Systems

Available types for different carrier frequencies

Type

TSOP1830QJ3V

TSOP1836QJ3V

TSOP1838QJ3V

TSOP1856QJ3V

fo

30 kHz

36 kHz

38 kHz

56 kHz

Type

TSOP1833QJ3V

TSOP1837QJ3V

TSOP1840QJ3V

fo

33 kHz

36.7 kHz

40 kHz

Description

The TSOP18..QJ3V 鈥?series are miniaturized

receivers for infrared remote control systems. PIN

diode and preamplifier are assembled on lead frame,

the epoxy package is designed as IR filter.

The demodulated output signal can directly be

decoded by a microprocessor. The main benefit is the

reliable function even in disturbed ambient and the

protection against uncontrolled output pulses.

16 078

Features

D

D

D

D

D

Photo detector and preamplifier in one package

Internal filter for PCM frequency

TTL and CMOS compatibility

Output active low

Improved shielding against electrical

field disturbance

Special Features

D

Small size package

D

Supply voltage 3鈥? Volt

D

Enhanced immunity against all kinds

of disturbance light

D

No occurrence of disturbance pulses

D

Short settling time after power on (<200

m

s)

at the output

D

Suitable burst length

鈮?

cycles/burst

Block Diagram

3

Input

Control

Circuit

80 k

W

1

PIN

AGC

Band

Pass

Demodu-

lator

2

GND

16249

V

S

OUT

Document Number 82143

Rev. 1, 19-Oct-00

www.vishay.com

1 (7)
