TSMS3700

Vishay Telefunken

GaAs Infrared Emitting Diode in SMT Package

Description

TSMS3700 is a standard GaAs infrared emitting diode

in a miniature PL鈥揅C鈥? package.

Its flat window provides a wide aperture, making it ideal

for use with external optics.

The diode is case compatible to the TEMT3700 photo-

transistor, allowing the user to assemble his own

optical interrupters.

Features

D

D

D

D

D

D

D

D

D

D

D

SMT IRED with high radiant power

Low forward voltage

Compatible with automatic placement equipment

EIA and ICE standard package

Suitable for infrared, vapor phase and wave-

solder process

Available in 8 mm tape

Suitable for DC and high pulse current operation

Wide angle of half intensity

蠒

=

鹵

60

擄

Peak wavelength

l

p

= 950 nm

High reliability

Matching to TEMT3700 phototransistor

94 8553

Applications

Infrared source in tactile keyboards

IR diode in low space applications

Matching with phototransistor TEMT3700 in reflective sensors

PCB mounted infrared sensors

Infrared emitter for miniature light barriers

Document Number 81037

Rev. 3, 01-Aug-00

www.vishay.com

1 (6)
