, Vgs @ - 4.5V, Ids @ - 7.5A =30m鈩?/div>
Features
Advanced trench process technology
High density cell design for ultra low on-resistance
High gate voltage
Block Diagram
Ordering Information
Part No.
TSM4835CS
Packing
Tape & Reel
Package
SOP-8
Absolute Maximum Rating
(Ta = 25
o
C
unless otherwise noted)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current, V
GS
@4.5V.
Pulsed Drain Current, V
GS
@4.5V
Maximum Power Dissipation
Ta = 25 C
Ta > 25
o
C
Operating Junction Temperature
Operating Junction and Storage Temperature Range
T
J
T
J
, T
STG
o
Symbol
V
DS
V
GS
I
D
I
DM
P
D
Limit
- 30
鹵 25
- 9.5
- 50
2.5
1.6
+150
- 55 to +150
Unit
V
V
A
A
W
W
o
o
C
C
Thermal Performance
Parameter
Junction to Ambient Thermal Resistance (PCB mounted)
Note: Surface mounted on FR4 board t<=5sec.
Symbol
R
胃ja
Limit
50
Unit
o
C/W
TSM4835
1-5
2003/12 rev. A
