TSLW1401

EXTENDED TEMPERATURE

128

y

1 LINEAR SENSOR ARRAY WITH HOLD

TAOS024A 鈥?JUNE 2001

D

D

D

D

Optical Glass Window

128

脳

1 Sensor-Element Organization

400 Dots-Per-Inch (DPI) Sensor Pitch

High Linearity and Uniformity

for 256 Gray-Scale (8-Bit) Applications

Output Referenced to Ground

Low Image Lag . . . 0.5% Typ

(TOP VIEW)

D

D

D

Operation to 2 MHz

D

Single 5-V Supply

Description

SI

CLK

AO

V

DD

1

2

3

4

8

7

6

5

GND

GND

GND

GND

The TSLW1401 linear sensor array consists of a 128

脳

1 array of photodiodes, associated charge amplifier

circuitry, and a pixel data-hold function that provides simultaneous-integration start and stop times for all pixels.

The pixels measure 63.5

碌m

(H) by 55.5

碌m

(W) with 63.5-碌m center-to-center spacing and 8-碌m spacing

between pixels. Operation is simplified by internal control logic that requires only a serial-input (SI) signal and

a clock.

Functional Block Diagram

Pixel 1

Integrator

Reset

Pixel

2

Pixel

3

Pixel

128

Analog

Bus

Output

Amplifier

Sample/

Output

3

AO

R

L

(External

Load)

V

DD

4

_

+

6,7

Switch Control Logic

GND

Hold

Q1

Q2

Q3

Q128

Gain

Trim

CLK

SI

2

1

128-Bit Shift Register

www.taosinc.com

Texas Advanced Optoelectronic Solutions Inc.

800 Jupiter Road, Suite 205

S

Plano, TX 75074

S

(972) 673-0759

t

t

Copyright

E

2001, TAOS Inc.

1
