r

r

TSL1401CS

128

脳

1 LINEAR SENSOR ARRAY WITH HOLD

TAOS036A - AUGUST 2003

D

D

D

D

D

D

D

D

D

D

128

脳

1 Sensor-Element Organization

400 Dots-Per-Inch (DPI) Sensor Pitch

High Linearity and Uniformity

Wide Dynamic Range . . . 4000:1 (72 dB)

Output Referenced to Ground

Low Image Lag . . . 0.5% Typ

Operation to 8 MHz

Single 3-V to 5-V Supply

Rail-to-Rail Output Swing (AO)

No External Load Resistor Required

(TOP VIEW)

1 SI

HOLD 2

3 CLK

GND 4

5 GND

Description

The TSL1401CS linear sensor array consists of a

128

脳

1 array of photodiodes, associated charge

amplifier circuitry, and a pixel data-hold function

that provides simultaneous-integration start and

stop times for all pixels. The pixels measure 63.5

碌m

(H) by 55.5

碌m

(W) with 63.5-碌m center-to-

center spacing and 8-碌m spacing between pixels.

Operation is simplified by internal control logic that

requires only a serial-input (SI) signal and a clock.

AO 6

7 SO

V

DD

8

Functional Block Diagram

Pixel 1

Integrator

Reset

Pixel

2

Pixel

3

Pixel

128

Analog

Bus

Output

Buffer

Sample/

Output

6

AO

8

V

DD

_

+

4, 5

GND

Switch Control Logic

2

Q1

Q2

Q3

Q128

Gain

Trim

7

SO

Hold

CLK

SI

3

1

128-Bit Shift Register

The

LUMENOLOGY

r

Company

Texas Advanced Optoelectronic Solutions Inc.

800 Jupiter Road, Suite 205

S

Plano, TX 75074

S

(972) 673-0759

r

www.taosinc.com

1

r

Copyright

E

2003, TAOS Inc.
