PIN CONNECTIONS
(top view)
N.C.
N.C.
N.C.
V
CC
+
Non-inve rting Input 1
Inverting Input 1
1
2
3
4
5
6
7
+
-
+
-
-
+
14 Output 3
13 Inverting Input 3
12 Non-inverting Input 3
11 V
CC
-
10 Non-inverting Input 2
9
8
Inverting Input 2
Output 2
DESCRIPTION
The TSH93 is a triple low power high frequency
op-amp, designated for high quality video signal
processing. The device offers an excellent speed
consumption ratio with 4.5mA/amp. for 150MHz
bandwidth.
High slew rate and low noise make it also suitable
for high quality audio applications.
June 1998
Output 1
1/9
