TSH321IDT Datasheet

  • TSH321IDT

  • Voltage-Feedback Operational Amplifier

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TSH321
WIDE BANDWIDTH AND MOS INPUT
SINGLE OPERATIONAL AMPLIFIER
s
s
s
s
s
s
LOW DISTORTION
GAIN BANDWIDTH PRODUCT : 300MHz
GAIN OF 2 STABILITY
SLEW RATE : 400V/碌s
VERY FAST SETTLING TIME : 60ns (0.1%)
VERY HIGH INPUT IMPEDANCE
DESCRIPTION
The TSH321 is a wideband monolithic operational
amplifier, requiring a minimum close loop gain of 2
for stability.
The TSH321 features extremely high input imped-
ance (typically greater than 10
12
鈩?
allowing direct
interfacing with high impedance sources.
Low distortion, wide bandwidth and high linearity
make this amplifier suitable for RF and video ap-
plications. Short circuit protection is provided by
an internal current-limiting circuit.
The TSH321 has internal electrostatic discharge
(ESD)
protection
circuits
and
fulfills
MILSTD883C-Class2.
ORDER CODE
Package
Part Number
TSH321I
Temperature Range
D
-40擄C, +125擄C
鈥?/div>
D
SO8
(Plastic Micropackage)
PIN CONNECTIONS
(top view)
Offset Null 1
Inverting Input
Non-inverting Input
V
CC
1
2
3
4
8
Offset Null 2
7 V
CC
+
6
5
Output
N.C.
D =
Small Outline Package (SO) - also available in Tape & Reel (DT)
October 2000
1/5
