TSH300 Datasheet

  • TSH300

  • Ultra Low-Noise High-Speed Operational Amplifier

  • 401.07KB

  • 18頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TSH300
Ultra Low-Noise High-Speed Operational Amplifier
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Structure: VFA
200 MHz bandwidth
Input noise: 0.65 nV/鈭欻z
Stable for gains > 5
Slew rate: 230 V/碌s
Specified on 100鈩?load
Tested on 5 V power supply
Single or dual supply operation
Minimum and maximum limits are tested in full
production
Pin Connections (top view)
OUT 1
-VCC 2
+IN 3
SOT23-5
5 +VCC
+-
4 -IN
Description
The TSH300 is a voltage feedback amplifier
featuring ultra-low input voltage and current noise.
This feature, associated with a large bandwidth,
large slew rate and a good linearity, makes the
TSH300 a good choice for high-speed data
acquisition systems where sensitivity and signal
integrity are the main priorities.
The TSH300 is a single operator available in SO8
and the tiny SOT23-5L plastic package, saving
board space as well as providing excellent
thermal performances.
NC 1
8 NC
_
+
7 +VCC
6
5 NC
SO8
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
-IN 2
+IN 3
-VCC 4
High speed data acquisition systems
Probe equipment
Communication & video test equipment
Medical instrumentation
ADC drivers
Order Codes
Part Number
TSH300ILT
TSH300ID
TSH300IDT
-40擄C to +85擄C
Temperature Range
Package
SOT23-5L
SO-8
SO-8
Packing
Tape & Reel
Tube
Tape & Reel
Marking
K308
TSH300I
TSH300I
Rev. 2
1/18
www.st.com
18
September 2005
