VISHAY
TSDF12830YS
Vishay Semiconductors
Dual - MOSMIC
廬
- two AGC Amplifiers for TV-Tuner Prestage
with Integrated Band Switch for One-Line Switching
Comments
MOSMIC
-
MOS Monolithic Integrated Circuit
VY
6
5
4
Description
The Dual-MOSMIC
廬
TSDF12830YS, assembled in
the well-known SOT-363 plastic package, is a combi-
nation of two different MOSMIC
廬
amplifiers with com-
mon Source and common Gate 2 leads and an
integrated switch. One of the MOSMIC stages is opti-
mized for use in VHF applications, especially regard-
ing cross modulation performance and noise figure at
lower VHF frequencies, whereas the other stage is
optimized for use in UHF applications regarding gain
and noise figure performance at higher frequencies of
UHF range. The integrated switch is operated by the
Gate 1 bias of the UHF amplifier on Pin 6. All of the
Gates are protected against excessive input voltage
surges by integrated antiserial diodes between them-
selves and Source.
CW
WM5
2
3
18597
1
Electrostatic sensitive device.
Observe precautions for handling
Typical Application
AGC
C
VHF
in
C
1
2
G2 (common)
RFC
D
3
C
+5 V
VHF
out
G1
AMP1
Features
鈥?Two differently optimized amplifiers in a single
package. One of them has a fully internal self-bias-
ing network on chip and the other has a partly inte-
grated bias for easy Gate 1 switch-off with PNP
switching transistors inside PLL -IC
鈥?Internal switch for saving lines on PCB layout as
well as external components
鈥?Integrated gate protection diodes
鈥?Low noise figure, high gain
鈥?Typical forward transadmittance of 31 mS
resp. 28 mS
鈥?Superior cross modulation at gain reduction
鈥?High AGC-range with soft slope
鈥?Main AGC control range from 3 V to 0.5 V
RG1
V
GG
UHF
in
C
6
G1
AMP2
RFC
D
4
C
+5 V
UHF
out
S (common)
5
V
GG
= 5 V: UHF AMP is on; VHF AMP is off
V
GG
= 0 V: UHF AMP is off; VHF AMP is on
(0 = shorted to Ground or open)
18598
Mechanical Data
Case:
SOT-363 Plastic case
Weight:
approx. 6.0 mg
V - Vishay
Y - Year, is variable for digit from 0 to 9
(e.g. 3 = 2003, 4 = 2004)
CW - Calendar Week, is variable for
number from 01 to 52
Number of Calendar Week is always indicating
place of pin 1
Pinning:
1 = Gate 1 (VHF amplifier), 2 = Gate 2 (common)
3 = Drain (VHF amplifier), 4 = Drain (UHF amplifier),
5 = Source (common), 6 = Gate1 (UHF amplifier)
www.vishay.com
1
Applications
Low noise gain controlled VHF and UHF input stages
with 5 V supply voltage, such as in digital and analog
TV tuners and in other multimedia and communica-
tions equipment.
Document Number 85171
Rev. 1.2, 25-Aug-04
