TS4264

150mA Ultra Low Drop Out Voltage Regulator

Pin assignment:

1. Input

2. Ground

3. Output

High Input Voltage up to 45V

Low Dropout Voltage 0.5V max.

General Description

TS4264 is a 5V low-drop fixed-voltage regulator in an SOT-223 package. The IC regulates an input voltage in the range

of 5.5V < Vin < 45V to Vout(rated) = 5.0V. The maximum output current is more than 150mA. This IC is designed with

short circuit-proof and features temperature protection that disables the circuit at over-temperature.

Features

Fixed output voltage 5V

Output voltage tolerance +/-2 %

150mA current capability

Ultra low drop out voltage

Very low current consumption

Over temperature protection

Short-circuit proof

Reverse polarity proof

Wide temperature range

Suitable for use in automotive electronics

Ordering Information

Part No.

TS4264CW50

Operating Temp.

-40 ~ 150

Package

SOT-223

Pin Definition and Function

Symbol

Input

Function

Block to ground directly on IC with

ceramic capacitor

Ground Ground

Output

Block to ground with 10uF capacitor,

ESR < 10鈩?/div>

銆€

Block Diagram

TS4264

1-1

2004/01 rev. A
