SN74CBTS3306
DUAL FET BUS SWITCH
WITH SCHOTTKY DIODE CLAMPING
SCDS029E 鈥?JANUARY 1996 鈥?REVISED NOVEMBER 1998
D
D
D
5-鈩?Switch Connection Between Two Ports
TTL-Compatible Input Levels
Package Options Include Plastic
Small-Outline (D) and Thin Shrink
Small-Outline (PW) Packages
D OR PW PACKAGE
(TOP VIEW)
description
1OE
1A
1B
GND
1
2
3
4
8
7
6
5
V
CC
2OE
2B
2A
The SN74CBTS3306 features independent line switches with Schottky diodes on the I/Os to clamp undershoot.
Each switch is disabled when the associated output-enable (OE) input is high.
The SN74CBTS3306 is characterized for operation from 鈥?0擄C to 85擄C.
FUNCTION TABLE
(each bus switch)
INPUT
OE
L
H
FUNCTION
A port = B port
Disconnect
logic diagram (positive logic)
2
1A
1
1OE
5
2A
7
2OE
6
2B
3
1B
