Small footprint due to small and thin package
High speed switching
Small gate charge: Qg = 48 nc (typ.)
Low drain-source ON resistance: R
DS (ON)
= 3.7 mO (typ.)
High forward transfer admittance: |Y
fs
| = 25 S (typ.)
Low leakage current: I
DSS
= 10 碌A (max) (V
DS
= 30 V)
Enhancement-mode: V
th
= 1.1 to 2.3 V (V
DS
= 10 V, I
D
= 1 mA)
Unit: mm
Maximum Ratings
(Ta = 25擄C)
Characteristics
Drain-source voltage
Drain-gate voltage (R
GS
=
20 k鈩?
Gate-source voltage
Drain current
DC
(Note 1)
Symbol
V
DSS
V
DGR
V
GSS
I
D
I
DP
P
D
Rating
30
30
鹵20
15
60
1.9
W
Unit
V
V
V
A
JEDEC
JEITA
TOSHIBA
?
?
2-6J1B
Pulsed (Note 1)
Drain power dissipation
(t
=
10 s)
(Note 2a)
Drain power dissipation
(t
=
10 s)
(Note 2b)
Single pulse avalanche energy
(Note 3)
Avalanche current
Repetitive avalanche energy
(Note 2a) (Note 4)
Channel temperature
Storage temperature range
Weight: 0.080 g (typ.)
P
D
E
A S
I
AR
E
AR
T
ch
T
stg
1.0
W
Circuit Configuration
146
15
0.19
150
鈭?5
to 150
mJ
8
7
6
5
A
mJ
擄C
擄C
1
2
3
4
Note: For (Note 1), (Note 2), (Note 3) and (Note 4), please refer to the
next page.
This transistor is an electrostatic sensitive device. Please handle with caution.
