TMS57535A
480CH 64G/S COLOR TFT SOURCE DRIVER
SLDS142 鈥?AUGUST 2001
D
Dot and N-Line Inversion Available
D
Six-Bit (64 Gray-Scale) Digital Driver
D
Mini-LVDS Level Input (Five Pairs of Serial
D
D
D
Data Inputs)
480 Output Ports (for UXGA Format)
V
DD
for Logic Port: 2.7 V to 3.6 V
V
DD
for LCD Driving Port: 8 V to 13.5 V
PACKAGE INFORMATION
The TCP鈥檚 external shape is customized. To
order the required shape, contact a TI sales
representative.
description
TMS57535A is a six bit (64 gray-scale) source
driver for TFT liquid-crystal display (LCD) with 480
output ports to deal with UXGA format.
Reduction in the number of input ports and
electromagnetic interference (EMI) is expected
with the introduction of mini-LVDS (low voltage
differential signaling) interface at the input ports.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
Copyright
錚?/div>
2001, Texas Instruments Incorporated
PRODUCT PREVIEW information concerns products in the formative or
design phase of development. Characteristic data and other
specifications are design goals. Texas Instruments reserves the right to
change or discontinue these products without notice.
POST OFFICE BOX 655303
鈥?/div>
DALLAS, TEXAS 75265
1
PRODUCT PREVIEW
