TMS320C6711D

FLOATING POINT DIGITAL SIGNAL PROCESSOR

SPRS292B 鈭?OCTOBER 2005 鈭?REVISED JUNE 2006

Excellent-Price/Performance Floating-Point

Digital Signal Processor (DSP):

TMS320C6711D

鈭?Eight 32-Bit Instructions/Cycle

鈭?167-, 200-, 250-MHz Clock Rates

鈭?6-, 5-, 4-ns Instruction Cycle Time

鈭?1000, 1200, 1500 MFLOPS

Advanced Very Long Instruction Word

(VLIW) C67x錚?DSP Core

鈭?Eight Highly Independent Functional

Units:

鈭?Four ALUs (Floating- and Fixed-Point)

鈭?Two ALUs (Fixed-Point)

鈭?Two Multipliers (Floating- and

Fixed-Point)

鈭?Load-Store Architecture With 32 32-Bit

General-Purpose Registers

鈭?Instruction Packing Reduces Code Size

鈭?All Instructions Conditional

Instruction Set Features

鈭?Hardware Support for IEEE

Single-Precision and Double-Precision

Instructions

鈭?Byte-Addressable (8-, 16-, 32-Bit Data)

鈭?8-Bit Overflow Protection

鈭?Saturation

鈭?Bit-Field Extract, Set, Clear

鈭?Bit-Counting

鈭?Normalization

L1/L2 Memory Architecture

鈭?32K-Bit (4K-Byte) L1P Program Cache

(Direct Mapped)

鈭?32K-Bit (4K-Byte) L1D Data Cache

(2-Way Set-Associative)

鈭?512K-Bit (64K-Byte) L2 Unified Mapped

RAM/Cache

(Flexible Data/Program Allocation)

Device Configuration

鈭?Boot Mode: HPI, 8-, 16-, 32-Bit ROM Boot

鈭?Endianness: Little Endian, Big Endian

Enhanced Direct-Memory-Access (EDMA)

Controller (16 Independent Channels)

32-Bit External Memory Interface (EMIF)

鈭?Glueless Interface to Asynchronous

Memories: SRAM and EPROM

鈭?Glueless Interface to Synchronous

Memories: SDRAM and SBSRAM

鈭?256M-Byte Total Addressable External

Memory Space

16-Bit Host-Port Interface (HPI)

Two Multichannel Buffered Serial Ports

(McBSPs)

鈭?Direct Interface to T1/E1, MVIP, SCSA

Framers

鈭?ST-Bus-Switching Compatible

鈭?Up to 256 Channels Each

鈭?AC97-Compatible

鈭?Serial-Peripheral-Interface (SPI)

Compatible (Motorola錚?

Two 32-Bit General-Purpose Timers

Flexible Software Configurable PLL-Based

Clock Generator Module

A Dedicated General-Purpose Input/Output

(GPIO) Module With 5 Pins

IEEE-1149.1 (JTAG

鈥?/div>

)

Boundary-Scan-Compatible

272-Pin Ball Grid Array (BGA) Package

(GDP and ZDP Suffixes)

CMOS Technology

鈭?0.13-碌m/6-Level Copper Metal Process

3.3-V I/O, 1.4-V Internal (鈭?50)

3.3-V I/O, 1.20-V Internal

鈥?/div>

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

TMS320C67x and C67x are trademarks of Texas Instruments.

Motorola is a trademark of Motorola, Inc.

All trademarks are the property of their respective owners.

鈥?IEEE Standard 1149.1-1990 Standard-Test-Access Port and Boundary Scan Architecture.

鈥?These values are compatible with existing 1.26V designs.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of Texas Instruments

standard warranty. Production processing does not necessarily include

testing of all parameters.

錚?/div>

2006, Texas Instruments Incorporated
