3 Year Product Warranty
compliant
RoHS
The TMR series is a range of miniature regulated 2 Watt DC/DC- converters in a SIL-
package. Requiring only 2cm
2
board space they provide a state of art functionality.
Wide 2:1 Input voltage range, 1000 VDC isolation voltage, external on/off control
and a temperature range of -40擄C 鈥?75擄C with no derating makes this converter
suitable for many applications in telecommunication, control units and industrial
equipments.
Models
Ordercode
TMR 0510
TMR 0511
TMR 0512
TMR 0521
TMR 0522
TMR 0523
TMR 1210
TMR 1211
TMR 1212
TMR 1221
TMR 1222
TMR 1223
TMR 2410
TMR 2411
TMR 2412
TMR 2421
TMR 2422
TMR 2423
TMR 4810
TMR 4811
TMR 4812
TMR 4821
TMR 4822
TMR 4823
http://www.tracopower.com
36 鈥?75 VDC
18 鈥?36 VDC
9 鈥?18 VDC
4.5 鈥?9.0 VDC
Input voltage range
Output voltage
3.3 VDC
5 VDC
12 VDC
鹵5 VDC
鹵12 VDC
鹵15 VDC
3.3 VDC
5 VDC
12 VDC
鹵5 VDC
鹵12 VDC
鹵15 VDC
3.3 VDC
5 VDC
12 VDC
鹵5 VDC
鹵12 VDC
鹵15 VDC
3.3 VDC
5 VDC
12 VDC
鹵5 VDC
鹵12 VDC
鹵15 VDC
Output current max.
500 mA
400 mA
167 mA
鹵200 mA
鹵83 mA
鹵67 mA
500 mA
400 mA
167 mA
鹵200 mA
鹵83 mA
鹵67 mA
500 mA
400 mA
167 mA
鹵200 mA
鹵83 mA
鹵67 mA
500 mA
400 mA
167 mA
鹵200 mA
鹵83 mA
鹵67 mA
Ef鏗乧iency typ.
64 %
66 %
71 %
64 %
69 %
71 %
70 %
73 %
80 %
73 %
78 %
78 %
71 %
74 %
81 %
74 %
78 %
80 %
70 %
73 %
79 %
71 %
77 %
77 %
Page 1 of 3
