TLE4264G Datasheet

  • TLE4264G

  • 5-V Low-Drop Fixed-Voltage Regulator

  • Infineon   Infineon

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TLE 4264 G
5-V Low-Drop Fixed-Voltage Regulator
TLE 4264 G
Features
q
q
q
q
q
q
q
Output voltage tolerance
鈮?鹵
2 %
Low-drop voltage
Very low current consumption
Overtemperature protection
Short-circuit proof
Suitable for use in automotive electronics
Reverse polarity
P-SOT223-4-1
Type
TLE 4264 G
Functional Description
Ordering Code
Q67006-A9139
Package
P-SOT223-4-1 (SMD)
TLE 4264 G is a 5-V low-drop fixed-voltage regulator in an SOT-223 package. The IC
regulates an input voltage
V
I
in the range 5.5 V <
V
I
< 45 V to
V
Qrated
= 5.0 V. The
maximum output current is more than 120 mA. This IC is shortcircuit-proof and features
temperature protection that disables the circuit at overtemperature.
Dimensioning Information on External Components
The input capacitor
C
i
is necessary for compensating line influences. Using a resistor of
approx. 1
鈩?/div>
in series with
C
i
, the oscillating of input inductivity and input capacitance can
be clamped. The output capacitor
C
Q
is necessary for the stability of the regulating
circuit. Stability is guaranteed at values
C
Q
鈮?/div>
10
碌F
and an ESR
鈮?/div>
10
鈩?/div>
within the
operating temperature range.
Semiconductor Group
1
1998-11-01

TLE4264G 產品屬性

  • Infineon

  • 低壓降 (LDO) 調節器

  • 45 V

  • 5 V

  • 0.5 V at 100 mA

  • 120 mA

  • 40 mV

  • 1

  • Fixed

  • + 150 C

  • SMD/SMT

  • SOT-223

  • + 5.5 V

  • - 40 C

  • Reel

  • 2 %

  • SP000011765 TLE4264GNT TLE4264GNTSA1
