TLE4250G Datasheet

  • TLE4250G

  • Low-Drop Voltage Tracker

  • Infineon   Infineon

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Low-Drop Voltage Tracker
TLE 4250 G
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Output tracking tolerance
鈮?鹵
0.5%
50 mA output current
Combined Tracking/Enable input
Very low current consumption in off mode
Low drop voltage
Suitable for use in automotive electronics
Wide operation range: up to 40 V
Wide temperature range: 鈥?40
擄
C
鈮?/div>
T
j
鈮?/div>
150
擄
C
Output protected against short circuit
Overtemperature protection
Reverse polarity proof
Very small SMD-Package SCT 595
Ordering Code
Q67006-A9351
SCT 595
Type
TLE 4250 G
Package
SCT-595 (SMD)
Functional Description
The TLE 4250 G is a monolithic integrated low-drop voltage tracker in the very small
SMD package SCT 595. It is designed to supply e.g. sensors under the severe
conditions of automotive applications. Therefore the device is equipped with additional
protection functions against overload, short circuit and reverse polarity.
Supply voltages up to 40 V are tracked to a reference voltage at the adjust input.
Therefore the Adjust pin has to be connected to a reference voltage, e.g. to a 5 V supply
on a micro-controller port.
The output is able to drive a load up to 50 mA while it follows the output of a main voltage
regulator within an accuracy of 0.5%.
The TLE 4250 G can be switched in stand-by mode via the adjust input which causes
the current consumption to drop to very low values. This feature makes the IC suitable
for low power battery applications.
Data Sheet Rev. 2.2
1
2000-10-04

TLE4250G 產品屬性

  • 3,000

  • 集成電路 (IC)

  • PMIC - 電源控制器，監視器

  • -

  • 低壓降跟蹤器

  • 4 V ~ 40 V

  • -

  • 80µA

  • -40°C ~ 150°C

  • 表面貼裝

  • 6-SMD（5 個接腳），鷗形翼

  • PG-SCT595-5

  • 帶卷 (TR)

  • SP000012163SP000950516TLE4250GXTTLE4250GXT-ND
