TLE4214G Datasheet

  • TLE4214G

  • Intelligent Double Low-Side Switch 2 x 0.5 A

  • 371.06KB

  • Infineon   Infineon

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Intelligent Double Low-Side Switch 2 x 0.5 A
TLE 4214 G
Bipolar IC
Features
q
q
q
q
q
q
q
q
Double low-side switch, 2 x 0.5 A
Power limitation
Overtemperature shutdown
Overvoltage shutdown
Status monitoring
Shorted-load protection
Integrated clamp diodes
Temperature range 鈥?40 to 125
擄C
P-DSO-20-7
Type
TLE 4214 G
Application
Ordering Code
Q67000-A9094
Package
P-DSO-20-7 (SMD)
Applications in automotive electronics require intelligent power switches activated by
logic signals, which are shorted-load protected and provide error feedback.
This IC contains two of these power switches (low-side switches). In case of inductive
loads the integrated clamp diodes clamp the discharging voltage. If a 鈥渉igh鈥?signal is
applied to the enable input both switches can be activated independently of one another
with TTL signals at the control inputs (active high). The high impedance inputs should
always be connected to a fixed potential (noise immunity).
The status output (open collector) signals the following malfunctions with high potential:
q
q
q
q
q
Overload,
Open load,
Shorted load to ground,
Overvoltage,
Overtemperature.
Semiconductor Group
294
10.96
