TK15325MTL/325 Datasheet

  • TK15325MTL/325

  • Audio Analog Switch

  • 12頁

  • TOKO   TOKO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TK15325
Audio Analog Switch
FEATURES
s
s
s
s
s
Wide Operating Voltage Range (
鹵
3 to
鹵
7 V)
Low Distortion (typ. 0.003%)
Wide Dynamic Range (typ. 6 V
P-P
)
Low Output Impedance (typ. 20
鈩?/div>
)
Low Switching Noise (typ. 3 mV)
APPLICATIONS
s
Audio Systems
s
Radio Cassettes
DESCRIPTION
The TK15325M is an Analog Switch IC that was developed
for audio frequency. Function is to select one output from
two inputs in a device that includes two circuits, and the
channel can be changed by low level. The TK15325M has
a dual power supply and the input bias is direct coupling at
GND level. Because the distortion is very low, the
TK15325M fits various signals switching. It is best suited
for Hi-Fi devices. Operating voltage is wide, the circuit
plan is simple. The TK15325M is available in a small
plastic surface mount package (SSOP-12).
TK15325
VCC
Bch
OUT
1ch-in
Ach
1KEY
NC
GND
11 Bch
10 OUT
9
8
7
Ach
2 KEY
NC
2ch-in
BLOCK DIAGRAM
VCC
Ach
+
-
1 ch out
1ch-in
1KEY
Bch
+
-
ORDERING INFORMATION
Ach
+
-
2 ch out
TK15325M
Tape/Reel Code
2ch-in
2KEY
Bch
+
-
GND
TAPE/REEL CODE
TL: Tape Left
June 1999 TOKO, Inc.
Page 1
