TK14588V/14588 Datasheet

  • TK14588V/14588

  • FM IF IC

  • 20頁

  • TOKO   TOKO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TK14588
FM IF IC
FEATURES
s
s
s
s
s
s
Input Frequency (~22 MHz)
Low Voltage Operation (2.3 to 5.5 V)
Battery Save Function
Wide Band Demodulator (~1 MHz)
High Speed Data Comparator (~2 Mbps)
Very Small Package (TSSOP-16)
APPLICATIONS
s
Communications Equipment
s
Wireless LAN
s
Keyless Entry Systems
TK14588V
IF INPUT
GND
RSSI
IF OUTPUT
DET INPUT
DET OUTPUT
AMP OUTPUT
COMP INPUT
COMP INPUT
DESCRIPTION
The TK14588V is a standard function general purpose IF
IC capable of operating up to 22 MHz. The TK14588V
contains a high-speed data comparator for base band
processing. The TK14588V has a unique function that
allows establishing the demodulation characteristics by
changing the external RC time constant, and not changing
the phase shifter constant. The RSSI output is individually
trimmed, resulting in excellent accuracy, good linearity,
and stable temperature characteristics. The TK14588V
was developed for high-speed data communication, DECT,
wireless LAN, keyless entry systems, etc.
The TK14588V is available in the very small TSSOP-16
surface mount package.
RSSI
GND
DECOUPLE
DECOUPLE
NC
POWER SAVE
VCC
COMP OUTPUT
COMP GND
BLOCK DIAGRAM
AMP OUTPUT
DET OUTPUT
GND
AMP
COMP INPUT
+
COMP
ORDERING INFORMATION
POWER SAVE
DECOUPLE
DECOUPLE
NC
VCC
COMP OUTPUT
COMP GND
IF INPUT
VCC
TK14588V
Tape/Reel Code
TAPE/REEL CODE
TL: Tape Left
January 2000 TOKO, Inc.
-
Page 1
COMP INPUT
DET INPUT
IF OUTPUT
+
-
