TIP152 Datasheet

  • TIP152

  • NPN SILICON POWER DARLINGTONS

  • 191.99KB

  • 7頁

  • POINN

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TIP150, TIP151, TIP152
NPN SILICON POWER DARLINGTONS
Copyright 漏 1997, Power Innovations Limited, UK
JUNE 1973 - REVISED MARCH 1997
q
q
q
q
q
80 W at 25擄C Case Temperature
7 A Continuous Collector Current
10 A Peak Collector Current
Maximum V
CE(sat)
of 2 V at I
C
= 5 A
I
CEX(sus)
7 A at rated V
(BR)CEO
B
C
E
1
2
3
TO-220 PACKAGE
(TOP VIEW)
Pin 2 is in electrical contact with the mounting base.
MDTRACA
absolute maximum ratings
at 25擄C case temperature (unless otherwise noted)
RATING
TIP150
Collector-base voltage (I
E
= 0)
TIP151
TIP152
TIP150
Collector-emitter voltage (I
B
= 0)
Emitter-base voltage
Continuous collector current
Peak collector current (see Note 1)
Continuous base current
Continuous device dissipation at (or below) 25擄C case temperature (see Note 2)
Continuous device dissipation at (or below) 25擄C free air temperature (see Note 3)
Operating junction temperature range
Storage temperature range
Lead temperature 3.2 mm from case for 10 seconds
NOTES: 1. This value applies for t
p
鈮?/div>
5 ms, duty cycle
鈮?/div>
10%.
2. Derate linearly to 150擄C case temperature at the rate of 0.64 W/擄C.
3. Derate linearly to 150擄C free air temperature at the rate of 16 mW/擄C.
TIP151
TIP152
V
EBO
I
C
I
CM
I
B
P
tot
P
tot
T
j
T
stg
T
L
V
CEO
V
CBO
SYMBOL
VALUE
300
350
400
300
350
400
8
7
10
1.5
80
2
-65 to +150
-65 to +150
260
V
A
A
A
W
W
擄C
擄C
擄C
V
V
UNIT
PRODUCT
INFORMATION
Information is current as of publication date. Products conform to specifications in accordance
with the terms of Power Innovations standard warranty. Production processing does not
necessarily include testing of all parameters.
1
