TFMS 5..0

Photo Modules for PCM Remote Control Systems

Available types for different carrier frequencies

Type

TFMS 5300

TFMS 5360

TFMS 5380

TFMS 5560

f

0

30 kHz

36 kHz

38 kHz

56 kHz

Type

TFMS 5330

TFMS 5370

TFMS 5400

f

0

33 kHz

36.7 kHz

40 kHz

Description

The TFMS 5..0 鈥?series are miniaturized receivers for in-

frared remote control systems. PIN diode and

preamplifier are assembled on lead frame, the epoxy

package is designed as IR filter.

The demodulated output signal can directly be decoded

by a microprocessor. The main benefit is the reliable

function even in disturbed ambient and the protection

against uncontrolled output pulses.

GND

V

S

OUT

94 8691

Features

D

Photo detector and preamplifier in one package

D

Output active low

(active high modules: TFMS 5..9)

D

Improved shielding against electric field

disturbance

D

Internal filter for PCM frequency

D

High immunity against ambient light

D

5 Volt supply voltage, low power consumption

D

TTL and CMOS compatibility

D

Continuous transmission possible (t

pi

/T 0.4)

x

Block Diagram

2

Input

Control

Circuit

100 k

W

3

PIN

AGC

Band

Pass

Demodu-

lator

1

GND

OUT

V

S

94 8136

TELEFUNKEN Semiconductors

Rev. A4, 15-Jul-96

1 (6)
