TDA8170

TV VERTICAL DEFLECTION OUTPUT CIRCUIT

.

.

.

.

The functions incorporated are :

POWER AMPLIFIER

FLYBACK GENERATOR

REFERENCE VOLTAGE

THERMAL PROTECTION

DESCRIPTION

The TDA8170 is a monolithic integrated circuit in

HEPTAWATT

TM

package. It is a high efficiency

power booster for direct driving of vertical windings

of TV yokes. It is intended for use in Colour and B

& W television receivers as well as in monitors and

displays.

PIN CONNECTIONS

7

6

5

4

3

2

1

Tab connected to Pin 4

REFERENCE VOLTAGE AND NON-INVERTING INPUT

OUTPUT STAGE SUPPLY

OUTPUT

GROUND

FLYBACK GENERATOR

SUPPLY VOLTAGE

INVERTING INPUT

HEPTAWATT

(Plastic Package)

ORDER CODE :

TDA8170

BLOCK DIAGRAM

+ V

S

2

6

3

FLYBACK

GENERATOR

RE FERENCE

VOLTAGE

1

PO WER

AMPLIFIER

5

THERMAL

P ROTECTION

TDA8170

4

YOKE

7

December 1997

1/7

8170-02.EPS

8170-01.EPS
