TDA8153 Datasheet

  • TDA8153

  • RGB VIDEO OUTPUT AMPLIFIER

  • 11頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TDA8153
RGB VIDEO OUTPUT AMPLIFIER
.
.
.
.
.
.
THREE INDEPENDENT VIDEO AMPLIFIERS
WITH TYPICAL SR > 1000V/碌s
CRT-CATHODE SENSING OUTPUT FOR SE-
QUENTIAL SAMPLING
INTERNAL G1 VOLTAGE GENERATOR
CATHODE SHORT CIRCUIT PROTECTION
FLASHOVER PROTECTION OF THE OUT-
PUT STAGES
COMPENSATES POSITIVE AND NEGATIVE
TUBE LEAKAGES
DESCRIPTION
Realized with a high voltage bipolar technology,the
TDA8153 is a monolithic RGB video output stage
for TV color applications. It drives the CRT cath-
odes directly and offers a video bandwidth compat-
ible with CCIR standards. In addition to three
independent video amplifiers, the device features
an internal generator for the first grid voltage,
flashover protection, cathode short circuit protec-
tion and a common cut-off sensing output for use
in sequential sampling applications.
The TDA8153 is supplied in a 15 lead Multiwatt
plastic power package.
PIN CONNECTIONS
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
MULTIWATT15
(Plastic Package)
ORDER CODE :
TDA8153
GREEN OUTPUT
BLUE FEEDBACK
BLUE OUTPUT
CUT-OFF
V
S
V
REF
BLUE INPUT
GROUND
GREEN INPUT
RED INPUT
FIRST GRIDE VOLTAGE
V
H
RED OUTPUT
RED FEEDBACK
GREEN FEEDBAC K
8153-01.EPS
Tab connected to Pin 8
January 1993
1/11
