TDA7513T Datasheet

  • TDA7513T

  • SINGLE-CHIP FM/AM TUNER WITH STEREO DECODER AND AUDIO PROCES...

  • 59頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TDA7513T
SINGLE-CHIP FM/AM TUNER WITH STEREO DECODER
AND AUDIO PROCESSOR
1
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
FEATURES
AM/FM TUNER FOR CAR-RADIO
INTEGRATED TUNING PLL
VARIABLE-BANDWITH FM IF FILTER (ISS)
FULLY INTEGRATED FM STEREO
DECODER
FULLY INTEGRATED FM NOISE BLANKER
HIGHLY INTEGRATED AUDIO PROCESSOR
Figure 1. Package
TQFP80
鈻?/div>
鈻?/div>
Table 1. Order Codes
Part Number
TDA7513T
Package
TQFP80
2
DESCRIPTION
The TDA7513T is the first device for car-radio ap-
plications that combines full RF front-end func-
tions with audio-processing capabilities.
As far as FM and AM functions are concerned , the
TDA7513T features front-end processing, includ-
ing the digital tuning PLL, IF processing with de-
modulation and variable-bandwidth IF filtering
(ISS), stop station and quality detection functions,
FM stereo decoding by means of a fully-integrat-
ed, adjustment-free dedicated PLL and, finally, FM
noise blanking. The FM stereo decoder and noise
blanker functions are realized entirely without ex-
ternal components.
The audio processor section comprises input se-
Figure 2. Pins Connection
FMIFAMP1OUT
lectors for two quasi-differential external sources,
volume control, tone control (bass, mid and tre-
ble), balance and fading control to drive four out-
put channels. A soft mute function and an RDS
mute function are included to handle source
change as well as RDS AF search without abrupt
changes in the audio level.
Most of the parameters in the front-end section are
I
2
Cbus-driven and therefore under the control of
the car-radio maker. The I
2
C bus allows further-
more the user to realize the full electric alignment
of all the external coils, therefore removing the
need for hand-made or mechanical adjustments.
FMIFAMP2OUT
FMIFAMPREF
AMIF2AMPIN
FMIFAMP1IN
FMIFAMP2IN
AMMIX2OUT
AMIF2AMPREF
AMAGC2TC
FMMIX2IN1
FMNAGCIN
MIX1OUT1
MIX1OUT2
FMMIX2IN2
80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61
VREF5V
TUNGND
AMMIX1IN1
AMMIX1IN2
AMAGC1TC
AMAGC1IOUT
AMAGC1VOUT
FMMIX1IN1
RFGND
FMMIX1IN2
FMAGCIOUT
FMWAGCIN
FMAGCVOUT
FMANTADJ
FMRFANDJ
OSCGND
VCOE
VCOB
OSCVCC
LFOUT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
MULTIPATHTC
RDSMUTE
AUDIOMUTE
QUALITY
SMETER
SD
SCL
SDA
FMMUTETC
TUNEROUT
TUNERIN
IN1L
IN1COM
IN1R
IN2R
IN2COM
IN2L
ACLOUT
ACLIN
ACROUT
IFGND
IFVCC
TUNVCC
TUNQUALITY
DIGVCC
DIGGND
VREF3V
OUTFR
OUTRL
XTALG
DEVTC
APGND
APVCC
PLLVCC
PLLGND
OUTRR
OUTFL
XTALD
LFREF
ACRIN
ISSTC
LFIN
LFHC
FMDEMREF
SMETERTC
DEMGND
D03AU1527
June 2004
REV. 1
1/59
