TDA7463AD

LOW VOLTAGE TONE CONTROL

DIGITALLY CONTROLLED AUDIO PROCESSOR

鈻?/div>

FEATURES

2 STEREO INPUT

1 STEREO OUTPUT

TREBLE BOOST

BASS CONTROL

BASS AUTOMATIC LEVEL CONTROL

VOLUME CONTROL IN 1dB STEPS

MUTE

STAND-BY FUNCTION SOFTWARE

CONTROLLED

ALL FUNCTION ARE PROGRAMMABLE VIA

SERIAL BUS

Figure 1. Package

SSO20P

Table 1. Order Codes

Part Number

TDA7463AD

Package

SSO20P

The control of all the functions is accomplished by

serial bus.

The AC signal setting is obtained by resistor net-

works and switches combined with operational

amplifiers.

Thanks to the used BIPOLAR/CMOS Technology,

Low Distortion, Low Noise and DC stepping are

obtained.

DESCRIPTION

The TDA7463AD is a volume tone (bass and tre-

ble) processor for quality audio applications in Low

voltage supply portable systems.

Bass ALC (Automatic Level Control) function can

be adjusted by a dedicated pin.

Figure 2. Block Diagram

5.6K

C14 3.3nF

100nF

C13

100nF

C12

TREBLE-R

C1 0.47碌F

IN2-R

INPUT

SELECT

-63dB

CONTROL

TREBLE

BASSI-R

BASSO-R

50K

C2 0.47碌F

IN1-R

0/-10dB

BASS

OUT-R

50K

I2C

HALF_WAVE

RECTIFIER

I2C BUS DECODER + LATCHES

SDA

SCL

1K鈩?/div>

DGND

SCL

SDA

BASS_ALC

CONTROL

C3 0.47碌F

ALC

C4 0.47碌F

IN1-L

TREBLE

50K

-63dB

CONTROL

BASS

0/-10dB

OUT-L

C5 0.47碌F

IN2-L

50K

D99AU1049

3.3nF

TREBLE-L

BASSI-L

100nF

REF

BASSO-L

SUPPLY

GND

CREF

22碌F

C10

100nF

C11

100碌F

100nF

5.6K

June 2004

REV. 3

1/11

標準包裝
66
類別
集成電路 (IC)
家庭
線性 - 音頻處理
系列
-
類型
音頻處理器
應用
-
安裝類型
表面貼裝
封裝/外殼
20-SSOP（0.209"，5.30mm 寬）
供應商設備封裝
20-SSOP
包裝
托盤
