TCZS8100

Vishay Telefunken

Matchable Pairs 鈥?Emitter and Detector

Description

Pairs of infrared-emitting diode and photologic

detector, matched in their optical and electrical

features. These pairs enable a lot of applications. They

can be used both for transmissive or reflective sensor

functions. The peak wavelength of the emitter is

l

= 950 nm. The detector consists of a photologic IC

with Schmitt trigger and open collector output.

Applications

D

Detection of opaque material, documents etc

D

Paper position sensor in copy machines

D

Position sensor for shaft encoder

96 12366

Features

D

Output level 鈥楲OW鈥?when infrared beam is not

interrupted

D

TTL compatible

D

Small dimensions

D

Detector provided with daylight filter

D

Emitter and detector in side view case

D

Miniature plastic case with lens

D

Operating angle

鹵 蠒

= 35

擄

Handling Precautions

Connect a capacitor C of 100 nF between V

S1

and ground in order to stabilize power supply voltage!

Order Instruction

Ordering Code

TCZS8100鈥揚AER

Remarks

Document Number 83772

Rev. A2, 20鈥揓ul鈥?9

www.vishay.com

1 (6)
