TCUT1200X01
Vishay Telefunken
Subminiature Dual Channel Optical Sensor with
Phototransistor Output
Description
This device has a compact construction where the
emitting-light source and the detector are located
face-to-face on the same optical axes.
The operating wavelength is 950 nm. The detector
side incorporates 2 phototransistors. Distance of both
channels is 0.8 mm.
Applications
D
Accurate position sensor for encoder,
D
Detection for motion direction,
D
Detection of motor speed and direction where high
reliability performance is required
14849
Features
D
Dual channel with 0.3 mm aperture
D
Channel 1 to channel 2 distance 0.8 mm
(optical center)
A
Cath
Cath
13894
Coll
E
E
D
Gap 2 mm
D
Package height: 4 mm
D
Surface Mountable Technology (SMD)
D
Parts shipped taped and reeled 2000 pcs/ reel
D
Soldering method according to
CECC00802 table 1, class B or C
D
Option X01:
High rel. devices for advanced applications
Order Instruction
Ordering Code
TCUT1200X01
Resolution (mm) / Aperture (mm)
0.24
/
0.3
Remarks
Document Number 83756
Rev. A3, 01鈥揓un鈥?9
www.vishay.com
1 (9)
