TCST1103 Datasheet

  • TCST1103

  • Transmissive Optical Sensor with Phototransistor Output

  • 9頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TCST110. up to TCST230.
Vishay Telefunken
Transmissive Optical Sensor with Phototransistor
Output
Description
This device has a compact construction where the
emitting-light sources and the detectors are located
face-to-face on the same optical axis. The operating
wavelength is 950 nm. The detector consists of a
phototransistor.
B)
Applications
D
Contactless optoelectronic switch, control and
counter
A)
15136
Features
D
Compact construction
D
No setting efforts
D
Polycarbonate case protected against
ambient light
95 10796
+
D
D
2 case variations
D
3 different apertures
D
CTR selected in groups
(regarding fourth number of type designation)
E
7.6
0.3鈥?/div>
+
Top view
Order Instruction
Ordering Code
TCST1103
A)
TCST2103
B)
TCST1202
A)
TCST2202
B)
TCST1300
A)
TCST2300
B)
Resolution (mm) / Aperture (mm)
0.6
/
1.0
0.4
0.2
/
/
0.5
0.25
Remarks
No mounting flags
With two mounting flags
No mounting flags
With two mounting flags
No mounting flags
With two mounting flags
Document Number 83764
Rev. A5, 08鈥揓un鈥?9
www.vishay.com
1 (9)

TCST1103 產品屬性

  • 85

  • 傳感器，轉換器

  • 光學 - 光斷續器 - 槽型 - 晶體管輸出

  • -

  • 0.122"（3.1mm）

  • 可傳導的

  • 光電晶體管

  • 60mA

  • 4mA

  • 70V

  • 10µs，8µs

  • 通孔

  • 開槽模塊，4 引線雙排

  • 管件

  • 無放大

  • -55°C ~ 85°C
