TCLD1000 Datasheet

  • TCLD1000

  • Optocoupler with Photodarlington Output

  • 10頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TCLD10.. Series
Vishay
Semiconductors
Optocoupler with Photodarlington Output
Description
The TCLD10.. Series consists of a darlington
phototransistor optically coupled to a gallium arsenide
infrared-emitting diode in a 4-lead SO6L package.
The elements are mounted on one leadframe using a
coplanar technique,
providing a fixed distance
between input and output for highest safety
requirements.
Applications
Circuits for safe protective separation against
electrical shock according to safety class II (reinforced
isolation):
15231
D
For appl. class I 鈥?IV at mains voltage
鈮?/div>
300 V
D
For appl. class I 鈥?III at mains voltage
鈮?/div>
600 V
according to VDE 0884, table 2, suitable for:
Switch-mode power supplies, line receiver,
computer peripheral interface, microprocessor
system interface.
4
3
1
2
VDE Standards
These couplers perform safety functions according to
the following equipment standards:
D
VDE 0884
Optocoupler for electrical safety requirements
(will be replaced by IEC 747鈥?鈥?.2.3)
C
D
IEC 950/EN 60950
D
VDE 0804
D
IEC 65
Safety for mains-operated electronic and related
household apparatus
Office machines (applied for reinforced isolation
for mains voltage
鈮?/div>
400 V
RMS
)
Telecommunication apparatus and data
processing
Order Instruction
Ordering Code
TCLD1000
CTR Ranking
>600%
Remarks
4 Pin = Single channel
Document Number 83516
Rev. A3, 19鈥揗ar鈥?1
15245
www.vishay.com
1 (10)

TCLD1000 產品屬性

  • TCLD1000

  • 3,000

  • 隔離器

  • 光隔離器 - 晶體管，光電輸出

  • -

  • 1

  • DC

  • 5000Vrms

  • 600% @ 1mA

  • -

  • 35V

  • 80mA

  • 60mA

  • 1V

  • 達林頓晶體管

  • 表面貼裝

  • 4-SOP

  • 管件
