TC7WBL125FK Datasheet

  • TC7WBL125FK

  • TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic

  • 6頁

  • TOSHIBA

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TC7WBL125FK
TENTATIVE
TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic
TC7WBL125FK
Dual Low-Voltage Bus Switch
The TC7WBL125FK is a low on-resistance, high-speed CMOS
2-bit bus switch with low voltage operation. This bus switch
allows the connections or disconnections to be made with minimal
propagation delay while maintaining Low power dissipation
which is the feature of CMOS.
When output enable (OE) is at low level, the switch is on; when
at high level, the switch is off.
P-MOS and N-MOS channel block also allows that the device is
suitable for analog signal transmission.
All inputs are equipped with protection circuits to protect the
device from static discharge.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Operating voltage: V
CC
= 2~3.6 V
High speed operation: t
pd
= 0.25 ns (max) @3 V
Ultra-low on resistance: R
ON
= 5
鈩?/div>
(typ.) @3 V
Electro-static discharge (ESD) performance: 鹵200 V or more (JEITA)
鹵2000 V or more (MIL)
High noise immunity: V
NIH
= V
NIL
= 28% V
CC
(min)
Power-down protection for inputs and I/O terminal.
Package: US8
Weight: 0.01 g (typ.)
Pin Assignment
(top view)
V
CC
OE2
8
7
B1
6
A2
5
WBL
125
1
2
OE1 A1
3
4
B2 GND
1
2001-10-16
