TC7MH367,368FK
TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic
TC7MH367FK,TC7MH368FK
HEX Bus Buffer
TC7MH367FK Non-Inverted, 3-State Outputs
TC7MH368FK Inverted, 3-State Outputs
The TC7MH367FK and TC7MH368FK are advanced high
speed CMOS HEX bus buffers fabricated with silicon gate
C
2
MOS technology.
They achieve the high speed operation similar to equivalent
bipolar schottky TTL while maintaining the CMOS low power
dissipation.
They contain six buffers; four buffers are controlled by an
enable input (G1), and the other two buffers are controlled by
another enable input (G2). The outputs of each buffer group are
Weight: 0.02 g (typ.)
enabled when G1 and/or G2 inputs are held low; if held high,
these outputs are in a high impedance state.
The TC7MH367FK is a non-inverting output type, while the TC7MH368FK is an inverting output type.
An input protection circuit ensures that 0 to 7 V can be applied to the input pins without regard to the supply
voltage. This device can be used to interface 5 V to 3 V systems and two supply systems such as battery back up.
This circuit prevents device destruction due to mismatched supply and input voltages.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High speed: t
pd
= 3.8 ns (typ.) (V
CC
= 5 V)
Low power dissipation: I
CC
= 4 碌A(chǔ) (max) (Ta = 25擄C)
High noise immunity: V
NIH
= V
NIL
= 28% V
CC
(min)
Power down protection is provided on all inputs.
Balanced propagation delays: t
pLH
鈮?/div>
t
pHL
Wide operating voltage range: V
CC (opr)
= 2~5.5 V
Low noise: V
OLP
= 0.8 V (max)
Pin and function compatible with 74ALS367/368
1
2001-10-23
