(min.). Capability of driving 50
鈩?/div>
transmission lines.
Balanced Propagation Delays:
t
pLH
= t
pHL
Wide Operating Voltage Range:
V
CC
(opr.) = 2V~5.5V
Pin and Function Compatible with 74F377
Available in DIP, SOIC and SOP Packages
The TC74AC377 is an advanced high speed CMOS OCTAL
D-TYPE FLIP-FLOP fabricated with silicon gate and double-
layer metal wiring C
2
MOS technology.
It achieves the high speed operation similar to equivalent
Bipolar Schottky TTL, while maintaining the CMOS low
power dissipation.
These 8-bit D-type flip-flops are controlled by a clock input
(CK) and a output enable input (G).
The signal level applied to the D inputs are transferred to Q
outputs during the positive going transition of CK.
When the G is high, the eight outputs are in a high imped-
ance state.
All inputs are equipped with protection circuits against
static discharge or transient excess voltage.
Truth Table
Pin Assignment
G
Q1
D1
D2
Q2
Q3
D3
D4
Q4
1
2
3
4
5
6
7
8
9
20
19
18
17
16
15
14
13
12
11
(TOP VIEW)
V
CC
Q8
D8
D7
Q7
L
Q6
D6
D5
Q5
CK
X:
X
Don鈥檛 care
X
NO CHANGE
L
H
H
L
L
G
H
CLOCK
X
DATA
X
Q
NO CHANGE
INPUTS
OUTPUT
GND
10
IEC Logic Symbol
(1)
G
(11)
CK
(3)
D1
(4)
D2
(7)
D3
(8)
D4
(13)
D5
(14)
D6
(17)
D7
(18)
D8
G1
1C2
2D
(2)
Q1
(5)
Q2
(6)
Q3
(9)
Q4
(12)
Q5
(15)
Q6
(16)
Q7
(19)
Q8
