TC563002ECT Datasheet

  • TC563002ECT

  • 150mA, 10V LDO with Shutdown

  • 16頁

  • MICROCHIP   MICROCHIP

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M
Features
TC56
Package Type
5-Pin SOT-23A
V
OUT
5
NC
4
150mA, 10V LDO with Shutdown
鈥?Low Dropout Voltage: 200mV typ. at 80mA,
380mV typ. at 160mA
鈥?High Output Current: 180mA (V
OUT
= 5.0V)
鈥?High Accuracy Output Voltage (鹵2%)
鈥?Low Power Consumption: 11碌A(chǔ) (Oper.),
0.1碌A(chǔ) (Shutdown)
鈥?Low Temperature Drift (鹵100ppm/擄C typ.)
鈥?Excellent Line Regulation (0.2%/V typ.)
鈥?Space Saving 5-Pin SOT-23A Package
鈥?Short Circuit Protection
鈥?Standard 2.5V, 3.0V and 3.3V Output Voltages
TC56
1
V
SS
2
V
IN
3
SHDN
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Battery Powered Devices
Cameras and Portable Video Equipment
Pagers and Cellular Phones
Solar Powered Instruments
Consumer Products
General Description
The TC56 is a low supply current (11碌A(chǔ) typical at
V
OUT
= 3V), low dropout CMOS linear regulator, with a
10V maximum input voltage range. CMOS construction
eliminates wasted ground current, typical of bipolar
regulators, for greater system efficiencies and longer
operating time in battery-powered systems. The TC56
enters shutdown mode when the shutdown control
input (SHDN) is low. During shutdown, the regulator is
shut off, and supply current falls to 0.1碌A(chǔ) maximum.
Normal operation is restored when SHDN is returned to
a logic high. Low current consumption, 10V supply
tolerance and space-saving 5-Pin SOT-23A packaging
makes the TC56 ideal for a wide variety of applications.
Device Selection Table
Output
Part Number Voltage
(V)*
TC562502ECT
TC563002ECT
TC563302ECT
2.5
3.0
3.3
Package
Temperature
Range
5-Pin SOT-23A -40擄C to +85擄C
5-Pin SOT-23A -40擄C to +85擄C
5-Pin SOT-23A -40擄C to +85擄C
*Other output voltages are available. Please contact
Microchip Technology Inc. for details.
Functional Block Diagram
V
OUT
10
碌
F
Tantalum
5
V
OUT
4
(NC)
TC56
V
SS
1
V
IN
2
SHDN
3
ON OFF Shutdown
Control
4.7
碌
F
Tantalum
V
IN
錚?/div>
2002 Microchip Technology Inc.
DS21436B-page 1
