TB2901H Datasheet

  • TB2901H

  • Maximum Power 47 W BTL 】 4-ch Audio Power IC

  • 17頁

  • TOSHIBA

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TB2901H
TOSHIBA Bi-CMOS Digital Integrated Circuit Silicon Monolithic
TB2901H
Maximum Power 47 W BTL 脳 4-ch Audio Power IC
The TB2901H is 4-ch BTL audio amplifier for car audio
applications.
This IC can generate higher power: P
OUT
MAX = 47 W as it
includes the pure complementary P-ch and N-ch DMOS output
stage.
It is designed to yield low distortion ratio for 4-ch BTL audio
power amplifier, built-in standby function, muting function, and
various kinds of protectors.
Additionally, high-side switch is built in.
Features
路
High power output
: P
OUT
MAX (1) = 47 W (typ.)
(V
CC
= 14.4 V, f = 1 kHz, JEITA max, R
L
= 4
鈩?
: P
OUT
MAX (2) = 43 W (typ.)
(V
CC
= 13.7 V, f = 1 kHz, JEITA max, R
L
= 4
鈩?
: P
OUT
MAX (3) = 80 W (typ.)
(V
CC
= 14.4 V, f = 1 kHz, JEITA max, R
L
= 2
鈩?
: P
OUT
(1) = 29 W (typ.)
(V
CC
= 14.4 V, f = 1 kHz, THD = 10%, R
L
= 4
鈩?
: P
OUT
(2) = 25 W (typ.)
(V
CC
= 13.2 V, f = 1 kHz, THD = 10%, R
L
= 4
鈩?
: P
OUT
(3) = 55 W (typ.)
(V
CC
= 14.4 V, f = 1 kHz, THD = 10%, R
L
= 2
鈩?
路
路
路
路
路
路
路
Low distortion ratio: THD = 0.015% (typ.)
(V
CC
= 13.2 V, f = 1 kHz, P
OUT
= 5 W, R
L
= 4
鈩?
Low noise: V
NO
= 90 碌Vrms (typ.)
(V
CC
= 13.2 V, R
g
= 0
鈩?
BW = 20 Hz~20 kHz, R
L
= 4
鈩?
Built-in standby switch function (pin 4)
Built-in muting function (pin 22)
Built-in high-side switch function (pin 25)
Built-in various protection circuits:
Weight: 7.7 g (typ.)
Thermal shut down, overvoltage, out to GND, out to V
CC
, out to out short
Operating supply voltage: V
CC (opr)
= 9~18 V (R
L
= 4
鈩?
Note 1: Since this device鈥檚 pins have a low withstanding voltage, please handle it with care.
1
2002-11-06
