TA8252H
TOSHIBA Bipolar Linear Integrated Circuit Silicon Monolithic
TA8252H
Max Power 37W BTL 脳 4ch Audio Power IC
The TA8252H is 4ch BTL audio power amplifier for car audio
application.
This IC can generate more high power: P
OUT
MAX = 37W
as it is included the pure complementary PNP and NPN
transistor output stage.
It is designed low distortion ratio for 4ch BTL audio power
amplifier,built鈭抜n stand鈭抌y function, muting function,clip
detector,and diagnosis circuit.
Additionally, the AUX.amplifier is built鈭抜n, it can make the beep
signal etc.output to 2 channnels (out
1
and 4).It contains various
kind of protectors for car audio use.
Features
路
High power
: P
OUT
MAX (1) = 37W (typ.)
(V
CC
=
14.4V,
f =
1kHz,
EIAJ max., R
L
= 4鈩?
: P
OUT
MAX (2) = 35W (typ.)
(V
CC
=
13.7V,
f =
1kHz,
EIAJ max., R
L
= 4鈩?
: P
OUT
(1) = 24W (typ.)
(V
CC
=
14.4V,
f =
1kHz,
THD =
10%,
R
L
= 4鈩?
: P
OUT
(2) = 21W (typ.)
(V
CC
=
13.2V,
f =
1kHz,
THD =
10%,
R
L
= 4鈩?
路
路
路
路
路
路
路
路
Built鈭抜n clip detector & diagnosis circuit.(pin(25))
Low distortion ratio: THD = 0.02% (typ.)
(V
CC
=
13.2V,
f =
1kHz,
P
OUT
= 5W, R
L
= 4鈩?
Weight: 9.8g (typ.)
Low noise: V
NO
= 0.10mV
rms
(typ.)
(V
CC
=
13.2V,
R
g
= 0鈩? G
V
= 26dB, BW = 20~20kHz)
Built鈭抜n stand鈭抌y switch function (pin(2))
Built鈭抜n multing function (pin(24))
Built鈭抜n AUX. amplifier from single input (pin(16)) to 2 channels output; out1 and 4
Built鈭抜n various protection circuit
: Thermal shut down, Over voltage, Out to GND, Out to V
CC,
Out to Out short.
Operating supply voltage: V
CC (opr)
= 9~18V
1
2002-10-30
