TA2157F/FN

TOSHIBA Bipolar Linear Integrated Circuit Silicon Monolithic

TA2157F,TA2157FN

Digital Servo Head Amp for CD System

TA2157F/FN is a digital servo head amp for a 3-beam pickup

used in CD systems.

Gain for RF signal generation amp can be freely set, supporting

CD-RW.

Combining with single-chip processor TC94A14F/FA/FB, a

CMOS digital servo, makes configuring CD systems simple.

TA2157F

Features

路

路

路

路

路

路

路

路

路

路

Low power dissipation digital servo head amp

Built-in amplifier for generating reference voltage (VRO)

Built-in auto laser power control (APC) amplifier

Built-in RF amplifier

Built-in RF signal automatic gain control (AGC) amplifier

Built-in gain change circuit for CD-RW

Built-in focus error and tracking error signal amplifiers

Built-in track count signal amplifier

Normal-, double-, and 脳4-speed operation

24-pin mini flat package

Weight

SSOP24-P-300-1.00: 0.3 g (typ.)

SSOP24-P-300-0.65A: 0.17 g (typ.)

TA2157FN

1

2002-11-21
