T90FJR Datasheet

IC型號：
T90FJR
PDF描述：
Dual Common Interface Hardware Controller- CIMax
文件大小：
610.14KB
PDF頁數：
41頁
芯片廠家：
ATMEL

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features

鈥?/div>

Module Interface

鈥?2 full independent module capability

鈥?Common Interface Standard compliant

DVB_CI (CENELEC EN-50221)

NRSS-B (SCTE IS-679 Part B)

DAVIC v1.2 (CA0 interface)

鈥?Memory PCMCIA compliance (R2)

8-bit data access

26-bit address Memory Card

鈥?Attribute Memory access (CIS, Tupple)

鈥?High speed capability

Up to 20Mbits/s on Command Interface

Up to 100Mbits/s on Transport Stream

鈥?Polling and Interrupt modes

鈥?Hot Insertion (Automatic and Reset VCC handling)

鈥?3.3V or 5V I/O buffers

鈥?/div>

PQFP 128 package

鈥?/div>

Host microprocessor Interface

鈥?Universal Control Signal Generator (UCSG)

鈥?PC Card control signals generation

鈥?Supports PowerPC, ARM, ST20, 68xxx, TMS, LSI 64008, TC81220F, IDTR3041 host

microprocessors

鈥?I2C port

CIMaX鈩?Set-up

Slot selection

鈥?Cascade mode management (up to 4 CIMaX鈩?

鈥?Chip Select bank and Interrupt facilities

鈥?3.3V or 5V I/O buffers

鈥?/div>

Digital Video Stream Interface

鈥?MPEG II Transport Stream compliant

鈥?3.3V or 5V I/O buffer for direct interface with FEC and DEMUX ICs

Dual Common

Interface

Hardware

Controller-

CIMax鈩?/div>

T90FJR

Description

The T90FJR, also called CIMaX鈩?controller is the hardware extension of SCM Micro-

systems鈥?second generation Common Interface integration package (CI Pack+鈩?. It

enables CI Driver software to directly address two complete independent Common

Interface modules.

As such, it contributes to offer an optimized, homogeneous and complete solution for

digital TV receiver manufacturer that wants quickly to implement the Common

Interface.

CIMaX鈩?includes the necessary I/Os to interface the MPEG Transport stream gener-

ated by the receiver demodulator and to daisy chain it through two modules and back

it to the demultiplexer. Voltage level translators allow to avoid any additional

component.

CIMaX鈩?interfaces with major digital TV receiver microprocessors. An I2C bus is

used for initialization and module selection, while a Universal Control Signal Genera-

tor (UCSG)maps CPU control bus into Command Interface control signals. To

minimize pin count, host address and data buses transit through external buffers that

are driven by CIMaX鈩?

CIMaX鈩?includes a memory mode that allows to use any of the two Common inter-

face slots to read/write a 8-bit PC Card Memory card. This feature gives the receiver

memory extension capability for software upgrade or better performance.

Rev. A 鈥?7-Sep-01

1
