Features

鈥?/div>

Input Comparator with Schmitt-trigger Characteristic

Input Clamping Current Capability of 鹵10 mA

Integrated Protection Cells (EMC, ESD, RF) Dedicated to All Input Stages

Shutdown by Junction-temperature Monitor

Reset with Hysteresis at Low Voltage

ESD Protection Acording to Human Body Model:

鹵2000 V (C = 100 pF, R = 1.5 k鈩?

鈥?/div>

Output Stage:

鈥?Short-circuit Protected

鈥?Load-dump Protected at 1 k鈩?/div>

鈥?Jump Start Possible

Description

The singel-channel driver IC includes one non-inverted and current-limited output

stage with an open collector. Thermal shutdown protects the output against critical

junction temperatures. The output can sink a current of 20 mA. The digital input has

Schmitt-trigger function with pull-up resistors to 5 V.

Figure 1.

Block Diagram

Single-channel

Driver IC with

Thermal

Monitoring

T6801

Thermal

shutdown

GND

Under-

voltage

detection

Rev. 4761A鈥揂UTO鈥?1/03
