SY10ELT23LZCTR Datasheet

  • SY10ELT23LZCTR

  • 3.3V DUAL DIFFERENTIAL LVPECL-to-LVTTL TRANSLATOR

  • 54.35KB

  • 4頁

  • MICREL   MICREL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

3.3V DUAL DIFFERENTIAL
LVPECL-to-LVTTL
TRANSLATOR
FEATURES
s
3.3V power supply
s
2.0ns typical propagation delay
s
<500ps typical output-to-output skew
s
Differential LVPECL inputs
s
24mA LVTTL outputs
s
Flow-through pinouts
s
Available in 8-pin SOIC package
ClockWorks鈩?/div>
SY10ELT23L
SY100ELT23L
DESCRIPTION
The SY10/100ELT23L are dual differential LVPECL-
to-LVTTL translators with +3.3V power supply. Because
LVPECL (Low Voltage Positive ECL) levels are used,
only +3.3V and ground are required. The small outline 8-
lead SOIC package and the low skew, dual gate design
of the ELT23L makes it ideal for applications which
require the translation of a clock and a data signal.
The ELT23L is available in both ECL standards: the
10ELT is compatible with positive ECL 10H logic levels,
while the 100ELT is compatible with positive ECL 100K
logic levels.
PIN CONFIGURATION/BLOCK DIAGRAM
PIN NAMES
Pin
Function
LVTTL Outputs
Differential LVPECL Inputs
+3.3V Supply
Ground
D
0
/D
0
/D
1
D
1
1
2
LVPECL
3
4
LVTTL
8
7
6
5
V
CC
Q
0
Q
1
GND
Q
n
D
n
V
CC
GND
Rev.: G
Amendment: 0
1
Issue Date: July 2000
