SVC234 Datasheet

  • SVC234

  • Varactor Diode for FM Receiver Electronic Tuning Use

  • 3頁

  • SANYO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Ordering number : ENN6085
SVC234
Diffused Junction Type Silicon Diode
SVC234
Varactor Diode for
FM Receiver Electronic Tuning Use
Features
鈥?/div>
鈥?/div>
Package Dimensions
unit : mm
1169A
[SVC234]
鈥?/div>
鈥?/div>
Low voltage (6.5V).
Twin type varactor diode with good large-signal
characteristics for FM receiver electronic tuning use.
Very small package permits SVC234-applied sets to
be compact and slim.
Since available also in tape reel package, automatic
insertion is supported.
0.5
0.4
0.16
0 to 0.1
3
Electrical Connection
Cathode
3
1
0.95 0.95
2
1.9
2.9
0.5
1.5
2.5
0.8
1.1
1 : Anode
2 : Anode
3 : Cathode
SANYO : CP
1
Anode
2
Anode
Specifications
Absolute Maximum Ratings
at Tc=25擄C
Parameter
Reverse Voltage
Junction Temperature
Storage Temperature
Symbol
VR
Tj
Tstg
Conditions
Ratings
16
125
鈭?5
to +125
Unit
V
擄C
擄C
Electrical Characteristics
at Tc=25擄C
Parameter
Breakdown Voltage
Reverse Voltage
Interterminal Capacitance
5
Symbol
V(BR)R
VR
C1V
C4.5V
C6.5V
Q
CR
鈭咰
m
Conditions
IR=10碌A(chǔ)
VR=10V
VR=1.0V, f=1MHz
VR=4.5V, f=1MHz
VR=6.5V, f=1MHz
VR=3.0V, f=100MHz
C1.0V / C6.5V
VR=1.0, 4.5, 6.5V, f=1MHz (Cmax
鈭?/div>
Cmin) / Cmin
Ratings
min
16
62.02
21.45
13.42
60
4.05
50
68.79
28.27
16.03
4.90
0.03
max
Unit
V
nA
pF
pF
pF
Quality Factor
Capacitance Ratio
Matching Tolerance
5
: Capacitance value per each diode.
Marking : SV
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
41601 GI IM No.6085-1/3
