Digital
Technical Specifications
Pixel resolution
Pixel size
Array size
Dynamic range
644 x 484 (VGA)
5.6 碌m x 5.6 碌m
3.6 mm x 2.7 mm
> 52 dB
0 to 24dB
2.05 V / lux-s
+ 37 dB
2.6 to 3.6 V
Active (30 frame/s)
< 30 mA
Suspend (no clk) < 10 碌A(chǔ)
Operating temperature
Package size
Lens
Package type
[-25 ; +70]擄C
10.6 mm x 8.7 mm x
5.8 mm
47擄 HFOV, f#2.8
14 pad SmOP
Description
The VS6502 is a VGA resolution SmOP sensor
module. SmOP technology combines the
image sensor and fixed focus lens system in a
single module. The SmOP sensor module is
connected to the PCB either via a socket or flex
option. The socket allows the PCB to use
standard reflow soldering techniques.
The sensor outputs 10-bit raw digital image
data which directly interface to a range of
STMicroelectronics companion processors via
4/5 wire interface.
An I
2
C interface allows the processor to
configure the device and control exposure and
gain settings.
There are three different digital video output
formats:
鈼?/div>
VGA
Analogue gain
Sensitivity (typical)
Signal/Noise ratio
Supply voltage
Power consumption
Ordering information
Ordering code
VS6502V015
XS0015/TR
Description
VS6502 sensor module
socket for sensor module
mode - 640 x 480 image size
QVGA mode - 320 x 240
鈼?/div>
Sub-sampled
image size
鈼?/div>
Window
Of Interest QVGA mode - 320 x 240
pixel
May 2004
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice.
1/2
