SPECIFICATIONS
1. PICTURE TUBE
Size
Gun
DefIection Angle
Neck Diameter
Phosphor
Transmission
Dot Pitch
Face Treatment
: 19 inch
: In-line
: 90擄
: 29.1 mm
: P22
: 46%
: 0.26 mm
: ARASC (Anti-Reflection &
Anti-Static Coating)
3. POWER SUPPLY
3-1. POWER RANGE
AC 90V~140V / 180V~264V (Auto Select), 50/60Hz,
2.5A Max.
3-2. POWER CONSUMPTION
MODE
NORMAL (ON)
STAND-BY
SUSPEND
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
OUT OF RANGE
POWER CONSUMPTION
LED COLOR
GREEN
less than 120 W
less than 15 W
ORANGE
less than 15 W
less than 5 W
less than 5 W
ORANGE
ORANGE
2. SIGNAL
2-1. HORIZONTAL & VERTICAL SYNC
1) Input Voltage Level : Low=0~0.8V, High=2.1~5.5V
2) Sync Polarity
: Positive or Negative
3) Composite Sync Signal
Vertical Sync Width :1H~10H.
Serration Pulse
: Non, 0.5H, 1H, EX-OR
Equalize Pulse
: Max 5H
* Remark: H=Horizontal Period
2-2. VIDEO INPUT SIGNAL
1) Voltage Level
: 0~0.7 V
a) Color 0, 0
: 0 Vp-p
b) Color 7, 0
: 0.467 Vp-p
c) Color 15, 0
: 0.7 Vp-p
2) Input Impedance : 75
鈩?/div>
3) Video Color
: R, G, B Analog
4) Signal Format
: Refer to Timing Chart
2-3. SIGNAL CONNECTOR
15 pin D-Sub Connector / BNC Connector
OFF
FAULT
4. DISPLAY AREA
4-1. Active Video Area
4-2. Display Color
4-3. Display Resolution
4-4. Video Bandwidth
: 350 262 mm (13.78" 10.31")
(Available for Full Screen)
: Full Colors
: 1600 Dots 1200 Lines
(Non-Interlace)
: 200 MHz
5. ENVIRONMENT
5-1. Operating Temperature: 10擄C~40擄C (50擄F~104擄F)
(Ambient)
5-2. Relative Humidity
: 10%~90%
(Non-condensing)
5-3. Altitude
: 10,000 ft
6. DIMENSIONS (WITH TILT/SWIVEL)
Width
: 458.0 mm (18.03'')
Depth
: 479.0 mm (18.86'')
Height
: 468.0 mm (18.43'')
7. WEIGHT (WITH TILT/SWIVEL)
Net. Weight
: 24.3 kg (53.58 lbs)
Gross Weight
: 29.2 kg (64.38 lbs)
2-4. SCANNING FREQUENCY
Horizontal
: 30 ~ 96 kHz
Vertical
: 50 ~ 160 Hz
-2-
