STUDIOWORKS7D Datasheet

  • STUDIOWORKS7D

  • Monitor_ICs:ST6371B1J2 LSC4360P 24LC2110A KIA358P KA393

  • 52頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

SPECIFICATIONS
1. PICTURE TUBE
Size
Gun
DefIection Angle
Neck Diameter
Phosphor
Transmission
Dot Pitch
Focus Type
Low Radiation
4. POWER SUPPLY
: 17 inch
: In-line
: 90隆
: 29.1 mm
: P22
: 51%
: 0.28 mm
: Double Focus
: MPR-II
4-1. POWER RATING
AC 90~264V (Free Voltage), 50/60Hz, 1.5A Max.
4-2. POWER CONSUMPTION
MODE
NORMAL (ON)
STAND-BY
SUSPEND
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
POWER CONSUMPTION
LED COLOR
GREEN
less than 120 W
less than 15 W
ORANGE
less than 15 W
less than 5 W
ORANGE
2. SIGNAL
2-1. HORIZONTAL & VERTICAL SYNC
1) Input Voltage Level : Low=0~0.4V, High=3.0~5.5V
2) Sync Polarity
: Positive or Negative
2-2. VIDEO INPUT SIGNAL
1) Voltage Level
: 0 ~ 0.7 Vp-p
a) Color 0, 0
: 0 Vp-p
b) Color 7, 0
: 0.467 Vp-p
c) Color 15, 0
: 0.7 Vp-p
2) Input Impedance : 75 錕?frac12;
3) Video Color
: R, G, B Analog
4) Signal Format
: Refer To Timing Chart
2-3. SIGNAL CONNECTOR
15 Pin D-Sub Connector
2-4. SCANNING FREQUENCY
Horizontal
: 30 ~ 65 kHz
Vertical
: 50 ~ 110 Hz
3. STEREO AUDIO
3-1. Input Voltage
3-2. Input Impedance
3-3. Amp Output
3-4. Speaker Impedance
3-5. Speaker Type
OFF
5. DISPLAY AREA
: 300 225 mm (11.81" 8.86")
(Available for Full Screen)
5-2. Display Color
: Full Colors
5-3. Display Resolution : 1280 Dots 1024 Lines
(Non-Interlace)
5-4. Video Bandwidth : 100 MHz
6. ENVIRONMENT
6-1. Operating Temperature : 10 ~ 35隆C (50 ~ 95隆F)
(Ambient)
6-2. Relative Humidity
: 8 ~ 80%
(Non-condensing)
6-3. Altitude
:10,000 ft
7. DIMENSIONS (WITHOUT TILT/SWIVEL)
Width
Depth
Height
: 465.0 mm (18.31 inch)
: 442.0 mm (17.40 inch)
: 435.5 mm (17.15 inch)
5-1. Active Video Area
: 0.7 Vrms
: 10 k錕?frac12; Min.
: 2 W + 2 W (THD : 3%)
:4錕?frac12;
: Bass Reflex Full Dome
Speaker (1-Way)
8. WEIGHT (WITHOUT TILT/SWIVEL)
Net. Weight
Gross Weight
: 19.5 kg (42.99 lbs)
: 23.5 kg (51.81 lbs)
-2-
