STTH506TTI
Tandem 600V HYPERFAST RECTIFIER
MAJOR PRODUCTS CHARACTERISTICS
I
F(AV)
V
RRM
Tj (max)
V
F
(max)
I
RM
(typ.)
5A
600 V (in series)
150 擄C
2.6 V
3.6 A
1
2
3
1
2
3
FEATURES AND BENEFITS
ESPECIALLY SUITED AS BOOST DIODE IN
CONTINUOUS MODE POWER FACTOR
CORRECTORS AND HARD SWITCHING
CONDITIONS
DESIGNED FOR HIGH dI
F
/dt OPERATION.
HYPERFAST RECOVERY CURRENT TO
COMPETE WITH SiC DEVICES. ALLOWS
DOWNSIZING OF MOSFET AND HEATSINKS
INTERNAL CERAMIC INSULATED DEVICES
WITH EQUAL THERMAL CONDITIONS FOR
BOTH 300V DIODES
INSULATION
(2500V
RMS
)
ALLOWS
PLACEMENT ON SAME HEATSINK AS
MOSFET FLEXIBLE HEATSINKING ON
COMMON OR SEPARATE HEATSINK.
MATCHED DIODES FOR TYPICAL PFC
APPLICATION
WITHOUT
NEED
FOR
VOLTAGE BALANCE NETWORK
Package Capacitance: C=7pF
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Insulated TO-220AB
DESCRIPTION
The TURBOSWITCH 鈥淗鈥?is an ultra high
performance diode composed of two 300V dice in
series. TURBOSWITCH 鈥淗鈥?family drastically cuts
losses in the associated MOSFET when run at
high dI
F
/dt.
ABSOLUTE RATINGS
(limiting values, for both diodes)
Symbol
V
RRM
I
F(RMS)
I
FSM
T
stg
Tj
Parameter
Repetitive peak reverse voltage
RMS forward current
Surge non repetitive forward current
Storage temperature range
Maximum operating junction temperature
tp = 10 ms sinusoidal
Value
600
14
60
-65 +150
+ 150
Unit
V
A
A
擄C
擄C
TM: TURBOSWITCH is a trademark of STMicroelectronics
June 2003 - Ed: 1A
1/5
STTH506TTI 產品屬性
1,000
分離式半導體產品
二極管，整流器 - 陣列
-
3.6V @ 5A
6µA @ 600V
5A
600V
25ns
標準
快速恢復 = 200mA（Io）
1 對串聯
通孔
TO-220-3
TO-220AB
管件
