STTA306 Datasheet

  • STTA306

  • TURBOSWITCH - ULTRA-FAST HIGH VOLTAGE DIODE

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
STTA306B
TURBOSWITCH
TM
ULTRA-FAST HIGH VOLTAGE DIODE
MAIN PRODUCT CHARACTERISTICS
I
F(AV)
V
RRM
t
rr
(typ)
V
F
(max)
3A
600 V
20 ns
1.65 V
K
FEATURES AND BENEFITS
SPECIFIC TO FREEWHEEL MODE OPERATIONS:
FREEWHEEL OR BOOSTER DIODE.
ULTRA-FAST, AND SOFT RECOVERY.
VERY LOW OVERALL POWER LOSSES IN
BOTH THE DIODE AND THE COMPANION
TRANSISTOR.
HIGH FREQUENCY OPERATIONS.
A
NC
DPAK
DESCRIPTION
The TURBOSWITCH is a very high performance
series of ultra-fast high voltage power diodes.
TURBOSWITCH family drastically cuts losses in
both the diode and the associated switching IGBT
or MOSFET in all freewheel mode operations and
is particulary suitable and efficient in motor control
ABSOLUTE RATINGS
(limiting values)
Symbol
V
RRM
I
F(RMS)
I
FRM
I
FSM
Tj
T
stg
Parameter
Repetitive peak reverse voltage
RMS forward current
Repetitive peak forward current
tp=5
碌s
F=5 kHz square
Value
600
6
20
35
125
- 65 to + 150
Unit
V
A
A
A
擄C
擄C
freewheel applications and in booster diode appli-
cations in Power Factor Control circuitries.
Packaged in DPAK, these 600V devices are par-
ticularly intended for use on 240V domestic mains.
Surge non repetitive forward current tp=10 ms sinusoidal
Maximum operating junction temperature
Storage temperature range
TM : TURBOSWITCH is a trademark from STMicroelectronics
November 1999 - Ed: 3C
1/8
