STPS30L30CT/CG/CG-1
LOW DROP POWER SCHOTTKY RECTIFIER
MAIN PRODUCT CHARACTERISTICS
A1
I
F(AV)
V
RRM
Tj (max)
V
F
(max)
FEATURES AND BENEFITS
n
n
n
n
n
2 x 15 A
30 V
150 擄C
0.37 V
A2
K
K
VERY SMALL CONDUCTION LOSSES
NEGLIGIBLE SWITCHING LOSSES
EXTREMELY FAST SWITCHING
LOW FORWARD VOLTAGE DROP
LOW THERMAL RESISTANCE
A2
A1
K
A1
A2
TO-220AB
STPS30L30CT
D
2
PAK
STPS30L30CG
DESCRIPTION
Dual center tap Schottky rectifiers suited for
Switch Mode Power Supply and high frequency
DC to DC converters.
Packaged in TO-220AB and D
2
PAK these devices
are intended for use in low voltage, high frequency
inverters, free-wheeling and polarity protection
applications.
ABSOLUTE RATINGS
(limiting values, per diode)
Symbol
V
RRM
I
F(RMS)
I
F(AV)
I
FSM
I
RRM
I
RSM
T
stg
Tj
dV/dt
Parameter
Repetitive peak reverse voltage
RMS forward current
Average forward current
Surge non repetitive forward current
Peak repetitive reverse current
Non repetitive peak reverse current
Storage temperature range
Maximum operating junction temperature *
Critical rate of rise reverse voltage
Tc = 140擄C
未
= 0.5
Per diode
Per device
Value
30
30
15
30
220
1
3
- 65 to + 150
150
10000
Unit
V
A
A
A
A
A
擄C
擄C
V/碌s
A2
K
A1
I
2
PAK
STPS30L30CG-1
tp = 10 ms Sinusoidal
tp = 2
碌s
F = 1kHz square
tp = 100碌s square
* :
dPtot
1
thermal runaway condition for a diode on its own heatsink
<
dTj
Rth
(
j
鈭?/div>
a
)
1/5
March 2000 - Ed: 4B
