STPS120L15 Datasheet

  • STPS120L15

  • LOW DROP OR-ING POWER SCHOTTKY DIODE

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
STPS120L15TV
LOW DROP OR-ing POWER SCHOTTKY DIODE
MAIN PRODUCT CHARACTERISTICS
I
F(AV)
V
RRM
Tj (max)
V
F
(max)
FEATURES AND BENEFITS
n
2 x 60 A
15 V
125 擄C
0.31 V
K2
A2
K1
A1
n
n
VERY LOW DROP FORWARD VOLTAGE FOR
LESS POWER DISSIPATION AND REDUCED
HEATSINK
INSULATED PACKAGE:
Insulated voltage = 2500 V
(RMS)
Capacitance = 45 pF
AVALANCHE CAPABILITY SPECIFIED
K2
A2
K1
A1
DESCRIPTION
Dual Schottky rectifier suited for Switched Mode
Power Supplies and DC to DC power converters.
Packaged in ISOTOP
TM
, this device is especially
intended for use as an OR-ing diode in fault
tolerant power supply equipments.
ABSOLUTE RATINGS
(limiting values, per diode)
Symbol
V
RRM
I
F(RMS)
I
F(AV)
I
FSM
I
RRM
P
ARM
T
stg
Tj
dV/dt
* :
RMS forward current
Average forward current
Surge non repetitive forward current
Repetitive peak reverse current
Repetitive peak avalanche power
Storage temperature range
Maximum operating junction temperature
Critical rate of rise of reverse voltage
Tc = 115擄C
未
=1
tp = 10 ms
Sinusoidal
tp = 2碌s
F = 1kHz
tp = 1碌s
Tj = 25擄C
Parameter
Repetitive peak reverse voltage
Value
15
160
60
1200
2
72030
- 65 to + 150
125
10000
Unit
V
A
A
A
A
W
擄C
擄C
V/碌s
ISOTOP
TM
dPtot
1
thermal runaway condition for a diode on its own heatsink
<
dTj
Rth
(
j
鈭?/div>
a
)
ISOTOP is a trademark of STMicroelectronics
July 2003 - Ed :54A
1/4
