LITE-ON
SEMICONDUCTOR
STPR805DB thru 820DB
REVERSE VOLTAGE -
50
to
200
Volts
FORWARD CURRENT -
8.0
Amperes
SUPER FAST
GLASS PASSIVATED RECTIFIERS
FEATURES
Glass passivated chip
Superfast switching time for high efficiency
Low forward voltage drop and high current capability
Low reverse leakage current
High surge capacity
Plastic package has UL flammability classification
94V-0
B
C
K
PIN
1
2
TO-220AC
L
M
D
A
E
TO-220AC
MAX.
MIN.
DIM.
14.22
15.88
A
10.67
9.65
B
3.43
2.54
C
6.86
D
5.84
9.28
8.26
E
F
G
I
H
J
N
G
H
-
12.70
6.35
14.73
F
MECHANICAL DATA
Case : TO-220AC molded plastic
Polarity : As marked on the body
Weight : 0.08 ounces, 2.24 grams
Mounting position : Any
PIN 1
PIN 2
CASE
5.33
4.83
0.51
1.14
I
J
0.30
0.64
K
3.53
4.09
L
3.56
4.83
M
1.14
1.40
2.92
2.03
N
All Dimensions in millimeter
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
鈩?/div>
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current
SYMBOL
STPR805DB
50
35
50
STPR810DB
100
70
100
8
100
1.3
0.8
STPR815DB
150
105
150
STPR820DB
200
140
200
UNIT
V
V
V
A
V
RRM
V
RMS
V
DC
I
(AV)
@T
C
=
125 C
Peak Forward Surge Current
8.3ms single half-sine-wave
superimposed on rated load (JEDEC Metod)
Maximum Forward
Voltage
I
F
=
8A
Maximum DC Reverse Current
at Peak Reverse Voltage
Typical Junction
Capacitance (Note 1)
Maximum Reverse Recovery Time (Note 2)
Typical Thermal Resistance (Note 3)
Operating and Storage Temperature Range
I
FSM
A
@T
J
=25 C
@T
J
=150 C
@T
J
=25 C
@T
J
=100 C
V
F
V
I
R
C
J
T
RR
R
0JC
10
500
45
25
3.0
-55 to +150
uA
pF
ns
C/W
T
J
,T
STG
C
REV. 3, 13-Sep-2001, KTGA03
NOTES :1.Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
2.Reverse Recovery Test Conditions:I
F
=0.5A,I
R
=1.0A ,I
RR
0.25A.
3.Thermal Resistance Junction to Case.
1
2
