0.8 to 2.5GHz frequency range
Detection diode voltage drop compensation
Temperature compensation
Fast response time
Low Power consumption
Chip Scale device
Low parasitic impedance
DESCRIPTION
The STPAC02F1 is an integrated RF detector for
power control chain. It has been developed to
convert the RF signal coming from the external
coupler into a DC signal usable by the mobile
digital stage. It is based on the use of two similar
diodes, one assuming the signal detection while
the second one is used to compensate the ambient
temperature effect. A biasing stage suppresses
the detection diode drop voltage effect. The use of
the IPAD technology allows the RF front-end
designer to save PCB area and to drastically
suppress the parasitic inductances of the package.
Target applications are cellular phones and PDA
using GSM, DCS, PCS, AMPS, TDMA , CDMA
and 800MHz to 2100MHz frequency ranges
.
BENEFITS
鈻?/div>
Flip-Chip package
PIN CONFIGURATION (ball side)
3
2
Not
used
GND
GND
GND
VBias
1
OUT
GND
RFin
A
B
C
The use of IPAD technology allows the RF
front-end designer to save PCB area and to
drastically suppress the parasitic inductances.
FUNCTIONAL DIAGRAM
Antenna
Coupler
Bias voltage
V
BIAS
RF input
DC output
OUT
Low pass
filter
Thermal
compensation
RF detector
STPAC02F1
GND
TM
: IPAD is a trademark of STMicroelectronics.
